Hydraulic Pump Component | HINAKA | AHPT Series

  • Driven by air pressure, the hydraulic pump will automatic stop when the hydraulic pressure reaches the setting value and automatic recharge the system for any pressure drop . It is the best choice to safety and steadily hold workpiece for cutting
  • It is most suitable for applications, which demand for high pressure and sustaining holding of workpiece.
  • Even continuous running for months, the oil temperature will not rise. This feature effectively remedies the high temperature problem of the motor hydraulic pump. In addition, it is different from other booster, this pneumatic driven pump can pump oil continuously.
  • As a pneumatic driven device, the cylinder can be instantly started or stopped, it has the merits of explosion-proof, energy-efficient and small size
  • Number of control valves can be selected as demand. Users may select double pumps model with high/low pressure pumps, large amount of oil output can degrease the action time for holding.

Mô tả

AHPT-04-D10-V4D Product Name Length Width Height Mounting Type Boosting Ratio Output Capacity Oil Pressure Valve Voltage 3/2 Valve Zero-leakage Circuit Oil-Circuit Control Actuation Pressure Compare
AHPT-04-D10-V4D 410 mm 357 mm 550 mm Standard Type 5.0:1.0 12 c.c. 25 kgf D : DC24V 01 : AC110V 02 : AC220V 03 : AC380V Four group of 3/2 Valve Zero-leakage Circuits V : electrical signal B : manual control A : pneumatic piloting 0.2Mpa – 0.7Mpa(2kgf/cm2 – 7kgf/cm2) compressed air
AHPT-10-D10-V4D Product Name Length Width Height Mounting Type Boosting Ratio Output Capacity Oil Pressure Valve Voltage 3/2 Valve Zero-leakage Circuit Oil-Circuit Control Actuation Pressure Compare
AHPT-10-D10-V4D 410 mm 357 mm 550 mm Standard Type 10.0:1.0 5 c.c. 50 kgf D : DC24V 01 : AC110V 02 : AC220V 03 : AC380V Four group of 3/2 Valve Zero-leakage Circuits V : electrical signal B : manual control A : pneumatic piloting 0.2Mpa – 0.7Mpa(2kgf/cm2 – 7kgf/cm2) compressed air
AHPT-25-D10-V4D Product Name Length Width Height Mounting Type Boosting Ratio Output Capacity Oil Pressure Valve Voltage 3/2 Valve Zero-leakage Circuit Oil-Circuit Control Actuation Pressure Compare
AHPT-25-D10-V4D 410 mm 357 mm 550 mm Standard Type 25.0:1.0 2.5 c.c. 125 kgf D : DC24V 01 : AC110V 02 : AC220V 03 : AC380V Four group of 3/2 Valve Zero-leakage Circuits V : electrical signal B : manual control A : pneumatic piloting 0.2Mpa – 0.7Mpa(2kgf/cm2 – 7kgf/cm2) compressed air
AHPT-44-D10-V4D Product Name Length Width Height Mounting Type Boosting Ratio Output Capacity Oil Pressure Valve Voltage 3/2 Valve Zero-leakage Circuit Oil-Circuit Control Actuation Pressure Compare
AHPT-44-D10-V4D 410 mm 357 mm 550 mm Standard Type 44.0:1.0 1.4 c.c. 220 kgf D : DC24V 01 : AC110V 02 : AC220V 03 : AC380V Four group of 3/2 Valve Zero-leakage Circuits V : electrical signal B : manual control A : pneumatic piloting 0.2Mpa – 0.7Mpa(2kgf/cm2 – 7kgf/cm2) compressed air
AHPT-64-D10-V4D Product Name Length Width Height Mounting Type Boosting Ratio Output Capacity Oil Pressure Valve Voltage 3/2 Valve Zero-leakage Circuit Oil-Circuit Control Actuation Pressure Compare
AHPT-64-D10-V4D 410 mm 357 mm 550 mm Standard Type 64.0:1.0 0.9 c.c. 320 kgf D : DC24V 01 : AC110V 02 : AC220V 03 : AC380V Four group of 3/2 Valve Zero-leakage Circuits V : electrical signal B : manual control A : pneumatic piloting 0.2Mpa – 0.7Mpa(2kgf/cm2 – 7kgf/cm2) compressed air
AHPT-100-D10-V4D Product Name Length Width Height Mounting Type Boosting Ratio Output Capacity Oil Pressure Valve Voltage 3/2 Valve Zero-leakage Circuit Oil-Circuit Control Actuation Pressure Compare
AHPT-100-D10-V4D 410 mm 357 mm 550 mm Standard Type 100.0:1.0 0.6 c.c. 500 kgf D : DC24V 01 : AC110V 02 : AC220V 03 : AC380V Four group of 3/2 Valve Zero-leakage Circuits V : electrical signal B : manual control A : pneumatic piloting 0.2Mpa – 0.7Mpa(2kgf/cm2 – 7kgf/cm2) compressed air
